(WIP) fa-diagrams
SVG diagrams built from Font-Awesome icons
RoadMap to v1
- Font-Awesome paths scrapping in build
- Node placing with links
- SVG output
- Node's icon rendering
- Simple links rendering
- Dashed links rendering
- Colors
- Sub-elements
- More options
- PNG output
- Unit testing
Summary
Install
Static scripts
Get the scripts from this repository dist folder
<script src="fa-diagrams-data.min.js"></script>
<script src="fa-diagrams.min.js"></script>
CDN (soon)
<script src="https://cdn.jsdelivr.net/npm/fa-diagrams@latest/dist/fa-diagrams-data.min.js"></script>
<script src="https://cdn.jsdelivr.net/npm/fa-diagrams@latest/dist/fa-diagrams.min.js"></script>
or
<script src="https://unpkg.com/fa-diagrams/dist/fa-diagrams-data.min.js"></script>
<script src="https://unpkg.com/fa-diagrams/dist/fa-diagrams.min.js"></script>
NPM (soon)
npm install fa-diagrams
Build from sources
You will need subversion installed (used for precise folder fetching in GitHub)
git clone https://github.com/klemek/fa-diagrams.git
cd fa-diagrams
npm install
node build.sh
Usage
Node module
const faDiagrams = require('fa-diagrams');
const data = {
options: {
font: 'Courier New'
},
nodes: [
{
name: 'node1',
icon: 'server',
bottom: {text: 'myserver' },
top: {icon: 'node'}
},
{
name: 'node2',
icon: 'globe',
bottom: {text: 'world'}
}
],
links: [
{
from: 'node1',
to: 'node2',
bottom: {text: 'Hello World!'}
}
]
};
const svg = faDiagrams.compute(data); // string containing xml data
Will produce the following diagram:
Html script
<head>
...
<script src="fa-diagrams-data.min.js"></script>
<script src="fa-diagrams.min.js"></script>
...
</head>
<body>
...
<script>
...
const svg = faDiagrams.compute(data); // string containing xml data
...
</script>
...
</body>
</html>
API
You must pass as argument an object containing 3 keys:
options
Key (/subkey) |
Default value | Info |
|---|---|---|
placing/max-link-length |
3 | maximum stretching of links between nodes |
placing/diagonals |
true |
allow diagonal links to be made |
rendering/beautify |
false |
output a readable SVG file |
rendering/scale |
128 | (in pixels) final icons size |
rendering/color |
black |
color of all elements |
rendering/h-spacing |
1.3 | how width is stretched comparing to height |
rendering/icons/scale |
1 | default scaling of icons (might be redefined in node definition) |
rendering/links/scale |
1 | default scaling of links (might be redefined in link definition) |
rendering/links/size |
0 | forced size/length of the links (0 means it will be computed from the distance between the nodes) (might be redefined in link definition) |
rendering/texts/font |
'Arial' |
font family of the texts (might be redefined in sub-elements definition) |
rendering/texts/font-size |
20 | font size of the texts (might be redefined in sub-elements definition) |
rendering/texts/font-style |
'normal' |
font style of the texts (see Font styles) (might be redefined in sub-elements definition) |
nodes
Array of object as following:
| Key | Type | Required | Info |
|---|---|---|---|
name |
string | yes | used in links to reference nodes |
icon |
string | yes | name of the Font-Awesome icon of the node (see Icon names) |
top, bottom, left, right |
string or object | no | see Sub-elements |
color |
string | no | redefined the color |
scale |
number | no | redefine this node icon scale |
x, y |
number | no | force the position of this node |
links
Array of object as following:
| Key | Type | Required | Info |
|---|---|---|---|
from |
string | yes | source node name |
to |
string | yes | destination node name |
type |
string | no | link's appearance (see Link types) |
top, bottom |
string or object | no | see Sub-elements |
color |
string | no | redefined the color |
scale |
number | no | redefine this link scale |
size |
number | no | forced size/length of the link |
Sub-elements
Elements meant to be drawn along-side a node/link.
There are two types: text and icons
Texts
You can just enter a string to be considered a text but you can define a text with more options as following:
| Key | Type | Required | Info |
|---|---|---|---|
text |
string | yes | value of your text |
color |
string | no | redefined the color |
font |
string | no | redefine the font family |
font-size |
number | no | redefine the font size |
font-style |
string | no | redefine the font style (see Font styles) |
Icons
You can define a relative icon with the following:
Key (/subkey) |
Type | Required | Info |
|---|---|---|---|
icon |
string | yes | name of the Font-Awesome icon of the sub-element (see Icon names) |
color |
string | no | redefined the color |
More info
Icon names
(soon)
Link types
(soon)
Font styles
(soon)
Examples
